Preconfiguration "Simple tank management"
Simple monitoring of level states in tanks
This preconfiguration can be activated when creating a new object (e.g. by "New object ..." in the local object menu or by pressing the Insert key after selecting the object) and is included in the group: "/ Technology / Tanks".
This preconfiguration can be created in the object: PmaFolder or PmaRoot.
- The preconfiguration creates an object of the PmaFolder type containing PmaPanel, PmaData, PmaTimer, PmaTrendGroup and PmaAlarmGroup objects.
- The preconfiguration is created including the panel (object of the PmaPanel type) is functional also a Web panel.
The preconfiguration displays the levels in tanks. It trends its status, alarms technological limits and allows to control the filling and draining of the tanks.
There is a script in the PmaTimer object named "Emul" that emulates the values in variables of the PmaData object. The variables tank1Level and tank2Level are connected to PmaTrendGroup and PmaAlarmGroup objects by ExtTrend and ExtAlarmAnalog.
These configurators can be set before the preconfiguration is created:
| The name of created object | Name of the object created in the tree of Pma objects. The maximum name length is 30 characters. This is a system name, so it must contain only alphanumeric and must not contain any diacritics (i.e. national dependent chars), empty string, spaces and the first character must not be a number.
Default: "Tanks" |
|---|---|
| Object scripting language | Application object scripting language
0 - vbscript
1 - javascript |
| Enable as Web component | Specifies whether this object has to be registered as a Web server component
After the preconfiguration is created, the "PmaPanel > Web server > Enable as Web component" configurator will be set to this value. |
| PmaWeb object | Path in the tree of Pma objects to the object PmaWeb, PmaWebFolder or PmaWebLang where the registration is carried out.
Macro expression can be used for input (it is evaluated after starting the application). After the preconfiguration is created, the "PmaPanel > Web server > PmaWeb object" configurator will be set to this value. |
History:
Pm8.00.05: Created
